IoTMQTT Panel in action – the full configuration is automatically generated by the dongle – See MANUAL -> MQTT -> IoTMQTT to reach the same in 5 minutesNEW JK Layout – you can chose DALY or JK layout from MISC PageOn yellow box , clear evidence taht the balancer is working. Pointed by red arrow … one battery with lower nominal capacitance to keep monitored !charging – discharging cycles over last 24h daily stored on the dongleIoT ONOFF MQTT Client APP on iOS – configured to subscribe to some BMS exported parameters
JK in the Middle – the others are DALYJK BMS – GPS Connector used by ScanLabs LOgger MQTTJK-BMS
